Product Details
Always striving toward excellence, Smart Weigh has developed to be a market-driven and customer-oriented enterprise. We focus on strengthening the capabilities of scientific research and completing service businesses. We have set up a customer service department to better provide customers with prompt services including order tracking notice. smart packaging system We have been investing a lot in the product R&D, which turns out to be effective that we have developed smart packaging system. Relying on our innovative and hard-working staff, we guarantee that we offer customers the best products, the most favorable prices, and the most comprehensive services as well. Welcome to contact us if you have any questions.This product has strong corrosion resistance capacity. Both the inner parts and its surface have been treated with acid cleaning.
Product Image
Model | SW-PL2 |
Weighing Range | 10 - 1000 g (can be customized) |
Bag Size | 50-300mm(L) ; 80-200mm(W) --can be customized |
Bag Style | Pillow Bag; Gusset Bag |
Bag Material | Laminated film; Mono PE film |
Film Thickness | 0.04-0.09mm |
Speed | 40 - 120 times/min |
Accuracy | 100 - 500g,≤±1%; > 500g,≤±0.5% |
Hopper Volume | 45L |
Control Penal | 7" Touch Screen |
Air Consumption | 0.8Mps 0.4m3/min |
Power Supply | 220V/50HZ or 60HZ; 15A; 4000W |
Driving System | Servo Motor |
※ Features
◆ Fully-automatically procedures from material feeding, filling and bag-making, date-printing to finished products output;
◇ Because of the unique way of mechanical transmission, so its simple structure, good stability and strong ability to over loading.;
◆ Multi-languages touch screen for various clients, English, French, Spanish, etc;
◇ Servo motor driving screw is characteristics of high-precision orientation, high-speed, great-torque, long-life, setup rotate speed, stable performance;
◆ Side-open of the hopper is made of stainless steel and is consist of glass,damp. material movement at a glance through the glass,air-sealed to avoid the leak, easy to blow the nitrogen, and the discharge material mouth with the dust collector to protect the workshop environment;
◇ Double film pulling belt with servo system;
◆ Only control touch screen to adjust bag deviation. Simple operation.
※ Application
It is suitable for smaller granule and powder, like rice, sugar, flour, coffee powder etc.
※ Product Certificate
