Product Details
Always striving toward excellence, Smart Weigh has developed to be a market-driven and customer-oriented enterprise. We focus on strengthening the capabilities of scientific research and completing service businesses. We have set up a customer service department to better provide customers with prompt services including order tracking notice. lays packing machine Today, Smart Weigh ranks the top as a professional and experienced supplier in the industry. We can design, develop, manufacture, and sell different series of products on our own combining the efforts and wisdom of all our staff. Also, we are responsible for offering a wide range of services for customers including technical support and prompt Q&A services. You may discover more about our new product lays packing machine and our company by directly contacting us.Adopting user-friendly philosophy, Smart Weigh is designed with a built-in timer by the designers. This timer is sourced from suppliers whose products all certified under CE and RoHS.
The Smart Weigh SW-P420 automatic vertical packing machine comprises several key structural components. At the core is the vertical frame, constructed from durable stainless steel to ensure corrosion resistance and ease of cleaning. The machine features a film feeding system that aligns and prepares packaging material for filling. A precise volumetric filler is integrated for accurate dispensing of various products, while the adjustable conveyor system ensures smooth product transfer. The sealing mechanism includes both horizontal and vertical seals, providing strong, airtight closures essential for maintaining product freshness.
Model | SW-P420 |
Bag size | Side width: 40- 80mm; Width of side seal: 5-10mm |
Max width of roll film | 420 mm |
Packing speed | 50 bags/min |
Film thickness | 0.04-0.10mm |
Air consumption | 0.8 mpa |
Gas consumption | 0.4 m3/min |
Power voltage | 220V/50Hz 3.5KW |
Machine Dimension | L1300*W1130*H1900mm |
Gross Weight | 750 Kg |
※ Features
◆ Mitsubishi or SIEMENS PLC control with stable reliable sealing jaws and cutter, high accuracy output and color screen, bag-making, measuring, filling, printing, cutting, finished bag in one hygienic operations;
◇ Separate circuit boxes for pneumatic and power control. Low noise, and more stable;
◆ Film-pulling with servo motor double belt: less pulling resistance, bag is formed in good shape with better appearance; belt is resistant to be worn-out.
◇ External film web releasing mechanism: simpler and easier installation of packing film;
◆ Only control touch screen to adjust bag deviation. Simple operation;
◇ Close down type mechanism, defending powder into inside of machine.
※ Application
SW-P420 vertical form fill and seal machines are suitable for many kinds of food, bakery, candy, cereal, dry food, pet food, vegetable, frozen food, plastic and screw, seafood, puffy food, shrimp roll, peanut, popcorn, ornmeal, seed, sugar and salt etc. which shape is roll, slice and granule etc.
This VFFS packing machine can equip with different weigh filler, to be an fully automatic vertical packaging system: multihead weigher vertical form fill seal machine for granular products(food and non food products), auger filler vertical packaging machines for powder, liquid filler VFFS machines for liquid products. Contact us for more solutions!
※ Product Certificate
