Model | SW-CD220 | SW-CD320 |
Control System | Modular Drive & 7" HMI | |
Weighing range | 10-1000 grams | 10-2000 grams |
Speed | 25 meters/min | 25 meters/min |
Accuracy | +1.0 grams | +1.5 grams |
Product Size mm | 10 | 10 |
| Detect Size | 10 | 10 |
| Sensitivity | Fe≥φ0.8mm Sus304≥φ1.5mm | |
Mini Scale | 0.1 grams | |
Reject system | Reject Arm/Air Blast/ Pneumatic Pusher | |
Power supply | 220V/50HZ or 60HZ Single Phase | |
Package size (mm) | 1320L*1180W*1320H | 1418L*1368W*1325H |
Gross Weight | 200kg | 250kg |
※ Features
Share same frame and rejector to save space and cost;
User friendly to control both machine on the same screen;
Various speed can be controlled for different projects;
High sensitive metal detection and high weight precision;
Reject arm, pusher, air blow etc reject system as option;
Production records can be downloaded to PC for analysis;
Reject bin with full alarm function easy for daily operation;
All belts are food grade & easy disassemble for cleaning.
※ Product Certificate
