Model | SW-C500 |
Control System | SIEMENS PLC & 7" HMI |
Weighing range | 5-20kg |
Max Speed | 30 box /min depends on product feature |
Accuracy | +1.0 grams |
Product Size | 100 |
Reject system | Pusher Roller |
Power supply | 220V/50HZ or 60HZ Single Phase |
Gross Weight | 450kg |
◆ 7" SIEMENS PLC & touch screen, more stability and easier to operate;
◇ Apply HBM load cell ensure high accuracy and stability (original from Germany);
◆ Solid SUS304 structure ensure stable performance and precise weighing;
◇ Reject arm, air blast or pneumatic pusher for selecting;
◆ Belt disassembling without tools, which is easier to clean;
◇ Install emergency switch at the size of machine, user friendly operation;
◆ Arm device show clients clearly for the production situation (optional);
It is suitable to check weight of various product, over or less weight will be rejected out,qualify bags will be passed to next equipment.
