1. Smart Weigh auto weighing machine is required to go through a range of tests. It has passed the tests such as drop or shock testing, hardness testing, mechanical properties, and mechanism cycling movement endurance.
2. This product has the desired safety. It will be tested rigorously to make sure it does not contain harmful substances such as lead and mercury.
3. The product, with many superior benefits, is used by more and more people.
Model | SW-LC12 |
Weigh head | 12 |
Capacity | 10-1500 g |
Combine Rate | 10-6000 g |
Speed | 5-30 bags/min |
Weigh Belt Size | 220L*120W mm |
Collating Belt Size | 1350L*165W mm |
Power Supply | 1.0 KW |
Packing Size | 1750L*1350W*1000H mm |
G/N Weight | 250/300kg |
Weighing method | Load cell |
Accuracy | + 0.1-3.0 g |
Control Penal | 9.7" Touch Screen |
Voltage | 220V/50HZ or 60HZ; Single Phase |
Drive System | Motor |
※ Features
◆ Belt weighing and delivery into package, only two procedure to get less scratch on products;
◇ Most suitable for sticky & easy fragile in belt weighing and delivery,;
◆ All belts can be take out without tool, easy cleaning after daily work;
◇ All dimension can be customize design according to product features;
◆ Suitable to integrate with feeding conveyor & auto bagger in auto weighing and packing line;
◇ Infinite adjustable speed on all belts according to different product feature;
◆ Auto ZERO on all weighing belt for more accuracy;
◇ Optional index collating belt for feeding on tray;
◆ Special heating design in electronic box to prevent high humidity environment.
※ Application
It is mainly apply in semi-auto or auto weighing fresh/frozen meat, fish, chicken, vegetable and various kinds of fruit, such as sliced meat, lettuce, apple etc.
※ Function
※ Product Certificate
Company Features
1. Smart Weigh now centers on producing .
2. Over the years, we have developed a strong market development ability. We have expanded many overseas markets including America, Australia, and Germany as our main targeting markets.
3. Our philosophy of auto weighing machine begins with the high quality standards. Call now! We hold the belief of weighing scale to be a professional enterprise. Call now!
| Model | DCS |
| Brand | Today Machine |
| Keyword | Quantitative Flour Packaging Machine |
| Main Function | Bagging Filling |
| Machine type | Semi- Automatic Packing System |
| Advantage | High Sensitive Photo Tracking System |
| Item | Automatic Weighing Packing Machine |
| Filling range | 10-2000g |
| Capacity | 10-60 Bags/min |
| Weight | 200kg |
Vibration weigher system
Touch screen in multi-language
Photoelectric sensor & pedal control
Full Stainless steel structure in GMP standard
| Model | Range | Error | Speed (pcs/min) | Power | Weight | Dimension |
| DCS-2KG-1H One head | 0-2000g | ±2g | 5-20 | 220V/110V, 50-60HZ, 600W | 180kg | 900x900x1890mm |
| DCS-2KG-2H Two head | 0-2000g | ±2g | 20-50 | 220V/110V, 50-60HZ, 600W | 180kg | 900x900x1890mm |
| DCS-2KG-4H Four head | 0-2000g | ±2g | 30-60 | 220V/110V, 50-60HZ, 800W | 200kg | 900x1200x1550mm |
More models available, please contact us for details.
