1. The machines used for Smart Weigh bagging machine is regularly maintained and upgraded.
2. The product quality is reliable, the performance is stable, the service life is long.
3. The product helps reduce power loss and increase energy efficiency. This will directly contribute to the reduction in production costs.
Model | SW-LC8-3L |
Weigh head | 8 heads |
Capacity | 10-2500 g |
Memory Hopper | 8 heads on third level |
Speed | 5-45 bpm |
Weigh Hopper | 2.5L |
Weighing Style | Scraper Gate |
Power Supply | 1.5 KW |
Packing Size | 2200L*700W*1900H mm |
G/N Weight | 350/400kg |
Weighing method | Load cell |
Accuracy | + 0.1-3.0 g |
Control Penal | 9.7" Touch Screen |
Voltage | 220V/50HZ or 60HZ; Single Phase |
Drive System | Motor |
※ Features
◆ IP65 waterproof, easy for cleaning after daily work;
◇ Auto feeding, weighing and delivery sticky product into bagger smoothly
◆ Screw feeder pan handle sticky product moving forward easily;
◇ Scraper gate prevents the products from being trapped into or cut. The result is more precise weighing,
◆ Memory hopper on third level to increase weighing speed and precision;
◇ All food contact parts can be take out without tool, easy cleaning after daily work;
◆ Suitable to integrate with feeding conveyor & auto bagger in auto weighing and packing line;
◇ Infinite adjustable speed on delivery belts according to different product feature;
◆ Special heating design in electronic box to prevent high humidity environment.
※ Application
It is mainly apply in auto weighing fresh/frozen meat, fish, chicken and various kinds of fruit, such as sliced meat, raisin, etc.
※ Function
※ Product Certificate
Company Features
1. Smart Weigh Packaging Machinery Co., Ltd is recognized as an expertise in the weight machine industry.
2. Our company has hired professional designers. Focusing on evolving trends and requirements of the markets, they are able to capture the very best of the latest market trends and select the highest grade of materials to create quality products with exceptional value.
3. bagging machine has become the perpetual pursuit of Smart Weigh Packaging Machinery Co., Ltd to improve himself. Ask! pouch packing machine has become the perpetual pursuit of Smart Weigh Packaging Machinery Co., Ltd to improve himself. Ask!
Scope of application
This machine is widely used to pack any loose,non-cohesive granule products of
the food,
phaeceutical,and chemical industries,such as soup mix,coffee,instant drink mix,desiccant,
monosodium glutamate,sugar,salt,cereal etc.
Specification
Model | MY-60KB |
Sealing type | Back sealing |
Capcity | 30-60 bags/min |
Range of measurement | 1-100ml |
Bag size | (L)15-160mm (W)20-100mm |
Power | 1850W |
Voltage | 380V/50HZ 220V/50-60HZ |
Packing material | Paper/the polyethylene,nylon/polyethylene,tea filter paper,etc |
Net weight | 260kg |
Overall dimensions | (L)800*(W)800*(H)2000mm |
Machine features:
1. This machine can finish : forming bag--measuring--material filling—sealing—counting—date code printing, all the work automatically;
2. Photoelectric and tracing system or computer system can be provided without your specific requirements.
3. The PLC controller has the advantages such as setting the length of the bag; the out put alarm and the speed and quantity with buttons;
4. This machine can be installed to code printer for 1-3 lines characters such as production and expiry date according to your special request.
Applicable packing film:
Paper/PE, PT/PE, PET/AL/PE, BOPP/PE, Tea filter paper and other compound materials can be heat sealed.
-
