Smart Weigh Combined Metal Detector and Checkweigher1
1. It is proved by practices that has the characteristics of visual inspection systems .
2. This product is widely recommended and valued for its superior quality and long-lasting performance.
3. While providing users with cost-effective products, Smart Weigh Packaging Machinery Co., Ltd is more focused on providing users with wholehearted services
4. Smart Weigh Packaging Machinery Co., Ltd owns competitive production with a strong brand appeal.
Model | SW-CD220 | SW-CD320 |
Control System | Modular Drive & 7" HMI | |
Weighing range | 10-1000 grams | 10-2000 grams |
Speed | 25 meters/min | 25 meters/min |
Accuracy | +1.0 grams | +1.5 grams |
Product Size mm | 10 | 10 |
| Detect Size | 10 | 10 |
| Sensitivity | Fe≥φ0.8mm Sus304≥φ1.5mm | |
Mini Scale | 0.1 grams | |
Reject system | Reject Arm/Air Blast/ Pneumatic Pusher | |
Power supply | 220V/50HZ or 60HZ Single Phase | |
Package size (mm) | 1320L*1180W*1320H | 1418L*1368W*1325H |
Gross Weight | 200kg | 250kg |
※ Features
Share same frame and rejector to save space and cost;
User friendly to control both machine on the same screen;
Various speed can be controlled for different projects;
High sensitive metal detection and high weight precision;
Reject arm, pusher, air blow etc reject system as option;
Production records can be downloaded to PC for analysis;
Reject bin with full alarm function easy for daily operation;
All belts are food grade & easy disassemble for cleaning.
※ Product Certificate
Company Features
1. With continuous efforts in technology innovation and visual inspection systems improvement, Smart Weigh Packaging Machinery Co., Ltd has gained more trust in the industry.
2. Smart Weigh Packaging Machinery Co., Ltd masters leading technology and is determined to make progress in metal detector machine field.
3. checkweigher system is Smart Weigh Packaging Machinery Co., Ltd original service theory, which fully shows its own superiority. Get more info! With visual inspection systems being its service philosophy, Smart Weigh Packaging Machinery Co., Ltd provides security metal detectors . Get more info! To establish the service philosophy of metal detector cost is the base of Smart Weigh Packaging Machinery Co., Ltd's work. Get more info! Smart Weigh Packaging Machinery Co., Ltd persists in the visual inspection machine service concept. Get more info!
Customized interface language PLC control automatic baby wipes/wet tissue/napkin packing machine
Main performance and structure features
1. Double motors, converter and PLC controller,flexible bag length setting and cutting,saving time and film.
2. human-machine interface, convenient and quick parameter settings.
3. Self diagnosis failure function, failure displayed clearly.
4. High sensitive optical electric color mark tracking system and digital input cut position, which make the sealing and cutting more accurate.
5. Separated PID control system for temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking on the knife and no waste of the film.
7. Simple driving system, reliable working, convenient maintenance.
8. All controlled by program, convenient for function adjusting and upgrading
Production Processing
Machine Specification
| Model | BG-350X |
| Film Width | 350mm |
| Bag length | 65-190mm,120-280mm |
| Bag width | 50-160mm |
| Product Height | Max.60mm |
| Film roll diameter | Max.320mm |
| Packing Speed | 40-80bags/min |
| Power Specification | 220V,50/60HZ,2.8KW |
| Machine size | (L)4020(W)720 (H)1320mm |
| Machine weight | 550kg |
Machine Details
Optional device
1. Date coder 2. Automatic Punching Device 3. Full Stainless 4. Large Touch Screen 5.Air filling device 6.Release the air 7. Gusset device 8.No empty bag function 9.Customized sealing patterns and notch 10.Automatic feeder
Application
Applying to the packing of various kinds of items with regular shape in many industries, like food, hardware, medical products, daily use products, stationary,toys, hotel supplies, electric products etc.
Warm Notice:Dear customer,if you are about to send enquiry to us,please send your product details to us together as below:
1).Product picture (need to see shape)
2).Product size .(not bag size)
3).If you have many differernt product size,please send Maximum size and minimum size to us.
4).If you have any other requests,we're very glad to customized for you.
Thanks for your support! : )
Bag type
Packaging Detail:
1.Packaging Details:Export and Sea-worthy standard wooden case
2. After inspection our machines are wrapped by plastic film and then carefully packed in wooden cases.
Dedusting & Cleaning >> lubricate Drive Parts >> Divide Machine Into Modules >> Wrap Modules With Plastic
Film >> Packing Modules into Plywood Cases >> Mark Shipping Mark In The Cases
3. If any special requirements, we will pack it as requested.
