1. Smart Weigh multiweigh systems is prepared using premium quality raw material and modish technology.
2. Our multi head scales boasts its fabulous properties of multiweigh systems .
3. There is continuous attention to quality throughout the production process.
4. This product makes work easier and reduces the need for employing many people. This has led to a reduction in human labor costs.
5. The refinement of this product has driven a boom in many industries. It makes efficient mass production and increased productivity become true.
Model | SW-M14 |
Weighing Range | 10-2000 grams |
Max. Speed | 120 bags/min |
Accuracy | + 0.1-1.5 grams |
Weigh Bucket | 1.6L or 2.5L |
Control Penal | 9.7" Touch Screen |
Power Supply | 220V/50HZ or 60HZ; 12A; 1500W |
Driving System | Stepper Motor |
Packing Dimension | 1720L*1100W*1100H mm |
Gross Weight | 550 kg |
※ Features
◇ IP65 waterproof, use water cleaning directly, save time while cleaning;
◆ Modular control system, more stability and lower maintenance fees;
◇ Production records can be checked at anytime or download to PC;
◆ Load cell or photo sensor checking to satisfy different requirements;
◇ Preset stagger dump function to stop blockage;
◆ Design linear feeder pan deeply to stop small granule products leaking out;
◇ Refer to product features, select automatic or manual adjust feeding amplitude;
◆ Food contact parts disassembling without tools, which is easier to clean;
◇ Multi-languages touch screen for various clients, English, French, Spanish, etc;
※ Dimensions
※ Application
It is mainly apply in automatic weighing various granular products in food or non-food industries, such as potato chips, nuts, frozen food, vegetable, sea food, nail, etc.
※ Function
※ Product Certificate
Company Features
1. Smart Weigh Packaging Machinery Co., Ltd is a star in multi head scales industry.
2. With the introduction of highly advanced technology, Smart Weigh not only satisfy the needs of customers, but also improve the technical force.
3. multiweigh systems has become the perpetual pursuit of Smart Weigh Packaging Machinery Co., Ltd to improve himself. Call now! 14 head multi head combination weigher has become the perpetual pursuit of Smart Weigh Packaging Machinery Co., Ltd to improve himself. Call now! liquid filling machine has become the perpetual pursuit of Smart Weigh Packaging Machinery Co., Ltd to improve himself. Call now!
