Smart Weigh measure smart packaging system in bulk for food labeling
1. Entire range of this product offered by us is hugely demanded owing to these features.
2. This product meets the requirements of safe use. Safety testing has been performed based on mechanical design/performance, the intent of the product, the conditions of use and more.
3. This product has a strong load capacity. Its dimensions are calculated based on the intended loads and strength of the material.
4. smart packaging system not only has advantages of packaging equipment systems , but also has a highly guaranteed quality.
Model | SW-PL2 |
Weighing Range | 10 - 1000 g (can be customized) |
Bag Size | 50-300mm(L) ; 80-200mm(W) --can be customized |
Bag Style | Pillow Bag; Gusset Bag |
Bag Material | Laminated film; Mono PE film |
Film Thickness | 0.04-0.09mm |
Speed | 40 - 120 times/min |
Accuracy | 100 - 500g,≤±1%; > 500g,≤±0.5% |
Hopper Volume | 45L |
Control Penal | 7" Touch Screen |
Air Consumption | 0.8Mps 0.4m3/min |
Power Supply | 220V/50HZ or 60HZ; 15A; 4000W |
Driving System | Servo Motor |
※ Features
◆ Fully-automatically procedures from material feeding, filling and bag-making, date-printing to finished products output;
◇ Because of the unique way of mechanical transmission, so its simple structure, good stability and strong ability to over loading.;
◆ Multi-languages touch screen for various clients, English, French, Spanish, etc;
◇ Servo motor driving screw is characteristics of high-precision orientation, high-speed, great-torque, long-life, setup rotate speed, stable performance;
◆ Side-open of the hopper is made of stainless steel and is consist of glass,damp. material movement at a glance through the glass,air-sealed to avoid the leak, easy to blow the nitrogen, and the discharge material mouth with the dust collector to protect the workshop environment;
◇ Double film pulling belt with servo system;
◆ Only control touch screen to adjust bag deviation. Simple operation.
※ Application
It is suitable for smaller granule and powder, like rice, sugar, flour, coffee powder etc.
※ Product Certificate
Company Features
1. Smart Weigh Packaging Machinery Co., Ltd provides the less expensive and more cost-effective smart packaging system to fulfill each customer needs.
2. Smart Weigh uses imported technology to help optimize integrated packaging systems .
3. Smart Weigh Packaging Machinery Co., Ltd is dedicated to constant improvement and constant innovation. Inquiry! Smart Weigh Packaging Machinery Co., Ltd continuously optimizes our service system and improve the quality and performance of automatic bagging system . Inquiry!
