Smart Weigh SW-PL3 Measure Cup Vertical Packing System
About Smart Weigh
Smart Package Beyond Expected
Smart Weigh is a global leader in high-precision weighing and integrated packaging systems, trusted by 1,000+ customers and 2,000+ packing lines worldwide. With local support in Indonesia, Europe, USA and UAE, we deliver turnkey packaging line solutions from feeding to palletizing.
Send Your Inqulry
More Choices
This matched product path helps long packets move through weighing, discharge and pouch loading with fewer blockages and more reliable batch delivery.
Designed for chips, biscuits, crackers and other bagged snacks, the system is configured around your filled bag dimensions, required pack quantity and production output.
The feeding configuration is matched to the connected bags discharged by your primary packaging machine. Smart Weigh reviews the chain length, filled bag dimensions and required bundle arrangement before confirming the system.
Model | SW-PL3 |
Weighing Range | 10 - 2000 g (can be customized) |
Bag Size | 60-300mm(L) ; 60-200mm(W) --can be customized |
Bag Style | Pillow Bag; Gusset Bag; Four side seal |
Bag Material | Laminated film; Mono PE film |
Film Thickness | 0.04-0.09mm |
Speed | 5 - 60 times/min |
Accuracy | ±1% |
Cup Volume | Customize |
Control Penal | 7" Touch Screen |
Air Consumption | 0.6Mps 0.4m3/min |
Power Supply | 220V/50HZ or 60HZ; 12A; 2200W |
Driving System | Servo Motor |
※ Features
◆ Fully-automatically procedures from material feeding, filling and bag-making, date-printing to finished products output;
◇ It is customize cup size according to various kinds of product and weight;
◆ Simple and easy to operate, better for low equipment budget;
◇ Double film pulling belt with servo system;
◆ Only control touch screen to adjust bag deviation. Simple operation.
※ Application
It is suitable for smaller granule and powder, like rice, sugar, flour, coffee powder etc.
