Model | SW-PL2 |
Weighing Range | 10 - 1000 g (can be customized) |
Bag Size | 50-300mm(L) ; 80-200mm(W) --can be customized |
Bag Style | Pillow Bag; Gusset Bag |
Bag Material | Laminated film; Mono PE film |
Film Thickness | 0.04-0.09mm |
Speed | 40 - 120 times/min |
Accuracy | 100 - 500g,≤±1%; > 500g,≤±0.5% |
Hopper Volume | 45L |
Control Penal | 7" Touch Screen |
Air Consumption | 0.8Mps 0.4m3/min |
Power Supply | 220V/50HZ or 60HZ; 15A; 4000W |
Driving System | Servo Motor |
※ Features
◆ Fully-automatically procedures from material feeding, filling and bag-making, date-printing to finished products output;
◇ Because of the unique way of mechanical transmission, so its simple structure, good stability and strong ability to over loading.;
◆ Multi-languages touch screen for various clients, English, French, Spanish, etc;
◇ Servo motor driving screw is characteristics of high-precision orientation, high-speed, great-torque, long-life, setup rotate speed, stable performance;
◆ Side-open of the hopper is made of stainless steel and is consist of glass,damp. material movement at a glance through the glass,air-sealed to avoid the leak, easy to blow the nitrogen, and the discharge material mouth with the dust collector to protect the workshop environment;
◇ Double film pulling belt with servo system;
◆ Only control touch screen to adjust bag deviation. Simple operation.
※ Application
It is suitable for smaller granule and powder, like rice, sugar, flour, coffee powder etc.
