Model | SW-C220 | SW-C320 | SW-C420 |
Control System | Modular Drive & 7" HMI | ||
Weighing range | 10-1000 grams | 10-2000 grams | 200-3000 grams |
Speed | 30-100bags/min | 30-90 bags/min | 10-60 bags/min |
Accuracy | +1.0 grams | +1.5 grams | +2.0 grams |
Product Size mm | 10 | 10 | 10 |
Mini Scale | 0.1 grams | ||
Reject system | Reject Arm/Air Blast/ Pneumatic Pusher | ||
Power supply | 220V/50HZ or 60HZ Single Phase | ||
Package size (mm) | 1320L*1180W*1320H | 1418L*1368W*1325H | 1950L*1600W*1500H |
Gross Weight | 200kg | 250kg | 350kg |
※ Features
◆ 7" modular drive & touch screen, more stability and easier to operate;
◇ Apply Minebea load cell ensure high accuracy and stability (original from Germany);
◆ Solid SUS304 structure ensure stable performance and precise weighing;
◇ Reject arm, air blast or pneumatic pusher for selecting;
◆ Belt disassembling without tools, which is easier to clean;
◇ Install emergency switch at the size of machine, user friendly operation;
◆ Arm device show clients clearly for the production situation (optional);
※ Product Certificate
