Model | SW-LC12 |
Weigh head | 12 |
Capacity | 10-1500 g |
Combine Rate | 10-6000 g |
Speed | 5-30 bags/min |
Weigh Belt Size | 220L*120W mm |
Collating Belt Size | 1350L*165W mm |
Power Supply | 1.0 KW |
Packing Size | 1750L*1350W*1000H mm |
G/N Weight | 250/300kg |
Weighing method | Load cell |
Accuracy | + 0.1-3.0 g |
Control Penal | 9.7" Touch Screen |
Voltage | 220V/50HZ or 60HZ; Single Phase |
Drive System | Motor |
※ Features
◆ Belt weighing and delivery into package, only two procedure to get less scratch on products;
◇ Most suitable for sticky & easy fragile in belt weighing and delivery,;
◆ All belts can be take out without tool, easy cleaning after daily work;
◇ All dimension can be customize design according to product features;
◆ Suitable to integrate with feeding conveyor & auto bagger in auto weighing and packing line;
◇ Infinite adjustable speed on all belts according to different product feature;
◆ Auto ZERO on all weighing belt for more accuracy;
◇ Optional index collating belt for feeding on tray;
◆ Special heating design in electronic box to prevent high humidity environment.
※ Application
It is mainly apply in semi-auto or auto weighing fresh/frozen meat, fish, chicken, vegetable and various kinds of fruit, such as sliced meat, lettuce, apple etc.
※ Function
※ Product Certificate
